Cross Laser Module

High-quality laser diode,optical glass lens, driver circuit and housing
Better line quality
High reliability, high stability, long life,low price.


Product Details

Specifications
Wavelength:405nm,450nm,532nm,635nm,650nm,780nm,808nm,850nm,980nm.
Output power:1mw to 200mw

Beam divergence:0.1mrad ~ 0.6mrad
Line thickness: Less then 2mm at 5m
Fan angle:10°~135°
Laser line accuracy:<30”(at 5m)
Operating Voltage:DC3V-5V
Operating Temperature:-10℃~70℃
Storage Temperature:-30℃~80℃
Dimensions:8mmx10mm,12mmx45mm 16mmx70mm,22mmx110mm or customer size.



Characteriscics
High-quality laser diode,optical glass lens, driver circuit and housing
Better line quality
High reliability, high stability, long life,low price.

Cross Laser Module

Applications
Machine vision
Industrial inspection
Industrial marking devices
3D contour mapping
