Sunday Optics manufactures high precison aspheric lens, the accuracy can be 0.5-10um. We professionally make complicated optical system, from design, manufacture to assambly. Material range from optical glass to infrared glass with Traditioanl polish and CNC polish. High Precison aspheric lens mainly used for Thermal image
Share:
Why Choose Our Glass Aspheric Lenses
Our glass aspheric lenses are manufactured with high precision, offering diameters from 5 to 600 mm and surface quality up to 10‑5. Surface irregularity is controlled to λ/4 (632.8 nm), with PV ranging from 0.5 to 10 µm, fully customizable per client specifications. We provide optical-grade JGS1 glass and infrared materials, with single-layer or multi-layer AR coatings spanning 350–1585 nm, or custom wavebands as needed.
Parameter
| Structure | Aspheric lens, Cylindrical Aspheric lens, Spherical Aspheric lens |
| Material | Optical glass, JGS1 |
| Diameters Available | 5mm to 600mm |
| Diameter Tolerance | +0.00/-0.02mm or customer design |
| Surface Quality | 10-5 |
| Surface Irregularity | λ/4 @632.8nm or customer design |
| PV | 0.5-10um |
| Thickness tolerance | +0/-0.02mm |
| Clear Aperture | >90% of Diameter |
| Chamfer | 0.05-0.5mmx45degree, according to customer's needs. |
| Centeration | 3 arcmin |
| Coating | Single Mag2, Multiple Layers AR Coating A: 350-650nm B: 650-1050nm C: 1050-1585nm D: Customer Design |
Applications
· Thermal Imaging Lenses – Optimized for high transmission and minimal field curvature in IR cameras and thermal systems.
· Laser Collimation & Fiber Coupling – High numerical aperture (NA) lenses designed for low aberration and precise beam alignment.
· OEM Camera & Optical Modules – Compact, high-precision aspheric lenses ideal for space-limited imaging systems.
· Analytical & Measurement Instruments – Replace multi-element systems with a single aspheric lens to reduce weight and simplify assembly.
FAQ - Glass Aspheric Lens
Q: What materials and coatings are available?
A: Standard material is JGS1 optical glass. Infrared materials are available on request. Coatings include single-layer MgF2 and multi-layer AR coatings from 350–1585 nm, with custom wavebands possible.
Q: What are the minimum and maximum diameters and tolerances?
A: Diameters range from 5–600 mm. Standard diameter tolerance is +0.00 / -0.02 mm, thickness tolerance +0 / -0.02 mm. Custom tolerances can be made per drawings.
Q: How is lens surface precision ensured?
A: Lenses are manufactured using CNC and traditional polishing, plus MRF for ultra-precision. Each lens is tested for PV, surface roughness, and wavefront error, with reports provided.
Q: Can you provide samples or small-batch production?
A: Yes, sample lenses are available for evaluation before mass production to ensure batch consistency.
Q: What applications are these lenses suitable for?
A: Thermal imaging, laser collimation, OEM optical modules, analytical and measurement instruments.
Q: Can lenses be customized for specific coatings or wavebands?
A: Yes, we can produce lenses with custom AR coatings, wavebands, and PV tolerances per your specifications.
Q: How fast is lead time for custom orders?
A: Lead time depends on diameter, coating, and quantity. Small samples can be shipped within 2–3 weeks; mass production lead times will be quoted per order.
