Advantage
It can meet zero absorption
The energy separation tolerance is small
The operating temperature has no upper limit
Resistance to extremely strong laser damage
Any Wavelength
Share:
Specifications
| Material | H-K9L or JGS1 |
| Standard Size(mm) | 8*8*8 10*10*10mm 12.7*12.7*12.7mm 25.4*25.4*25.4mm 38.1*38.1*38.1mm 50.8*50.8*50.8mm 100*100*100mm |
| T:R | 1:9 2:8 3:7 4:6 5:5 6:4 7:3 8:2 9:1 |
| Size Tol. | -0.2mm |
| Surface Quality | 40-20 |
| Surface Flatness | 1/8 lambda@633nm |
| Absorption: | <10% |
| Polarization: | Tp-Ts& Rs-Rp<3% |
| Wavelength | 400-700nm, 700-1100nm, 1100-1600nm, 1500-2000nm |
| AOI of Splitter | 45°+/-15 |
| Coating | Bevel coated with dielectric npbs coating, all input and output coated with AR Ravg<0.5% |
| Glue | Optical glue or optical contact |
| Temperature | no limitation |
| Laser Damage | 15J/cm2@1064nm, 20ns, 20HZ |
